Electrical Steel GO Bread

Cold Rolled Grain Oriented Electrical (Silicon) Steel for Transformer Industry

We are experts in procuring and distributing Grain Oriented electrical steel for transformer manufacturers through our global network of partners.

We stay current with all technological advancements worldwide, with a specific focus on Grain Oriented Electrical Steel production, manufacturing techniques, and upcoming R&D developments.

Our expertise allows us to maintain close relationships and collaborate with numerous transformer manufacturers globally.

Utilizing our position, we are able to present you with offers of alternative products from various manufacturers that align with your specific technological needs.

Our goal is to provide not only customers or manufacturers but the most cost-efficient products for your projects from around the globe, while maximizing financial support for our partners.

We are equipped to provide competitively priced finished or cut core lamination to meet the needs of our partners.

  • PRIME MOTHER / SLIT COILS
  • EXCESS PRIME / SECONDARY MATERIAL
  • CUT CORE LAMINATION
    • STEP-LAP CORE
      • POWER TRANSFORMER CORES / 10 MVA UP TO 1000 MVA CUT CORE LAMINATION
      • DISTRIBUTION TRANSFORMER CORES / 50 KVA UP TO 10 MVA CUT CORE LAMINATION / FINISHED CORES
    • UNICORE / JENCORE
    • WOUND CORE
    • TORIODEL CORE
    • E and I

GO THICKNESS TABLE

THICKNESS

GRADE

MAX CORE LOSS

0.18 mm

H-Bi18-65

0.65 W/Kgs @ 1.7T/50Hz.

0.18 mm

M2

0.90 W/Kgs @ 1.7T/50Hz.

0.20 mm

H-Bi20-70

0.70 W/Kgs @ 1.7T/50Hz.

0.20 mm

H-Bi20-75

0.75 W/Kgs @ 1.7T/50Hz.

0.23 mm

H-Bi23-75

0.75 W/Kgs @ 1.7T/50Hz.

0.23 mm

H-Bi23-80

0.80 W/Kgs @ 1.7T/50Hz.

0.23 mm

H-Bi23-85

0.85 W/Kgs @ 1.7T/50Hz.

0.25 mm

DH-Bi25-60

0.60 W/Kgs @ 1.7T/50Hz.

0.27 mm

H-Bi27-85

0.85 W/Kgs @ 1.7T/50Hz.

0.27 mm

H-Bi27-90

0.90 W/Kgs @ 1.7T/50Hz.

0.27 mm

MoH27-95

0.95 W/Kgs @ 1.7T/50Hz.

0.27 mm

MoH27-100

1.00 W/Kgs @ 1.7T/50Hz.

0.27 mm

MoH27-110

1.10 W/Kgs @ 1.7T/50Hz.

0.27 mm

RGO27-120

1.20 W/Kgs @ 1.7T/50Hz.

0.30 mm

MoH30-105

1.05 W/Kgs @ 1.7T/50Hz.

0.30 mm

MoH30-110

1.10 W/Kgs @ 1.7T/50Hz.

0.30 mm

RGO30-120

1.20 W/Kgs @ 1.7T/50Hz.

0.30 mm

RGO30-125

1.25 W/Kgs @ 1.7T/50Hz.

0.35 mm

RGO35-130

1.30 W/Kgs @ 1.7T/50Hz.

0.35 mm

RGO35-145

1.45 W/Kgs @ 1.7T/50Hz.

0.35 mm

RGO35-155

1.55 W/Kgs @ 1.7T/50Hz.

0.35 mm

RGO35-165

1.65 W/Kgs @ 1.7T/50Hz.
